Name: Dell Optiplex 3040 SFF, Intel H110,1151 pin sorunsuz anakart
Brand: Dell
SKU: 1278770363
Price: 2000.00 TRY
Availability: InStock

Açıklama

Test edilmiştir sorunsuz çalışıyor hiçbir aksamında sorun yoktur,

Resimler ürüne aittir

Bios günceldir

3 ay deneme garantisi

Table 1. Processor

Feature	Specification
Processor type	6th Generation Intel Core i3/i5/i7 series Intel Celeron Intel PDC
Total cache	Up to 8 MB cache depending on processor type

Table 2. Memory

Feature	Specification
Type	DDR3L
Speed	1600 MHz
Connectors	Two UDIMM slots
Memory module capacity	2 GB,4 GB and 8 GB
Minimum memory	2 GB NOTE: The minimum memory may differ based on the operating system installed on the computer.
Maximum memory	16 GB NOTE: Each UDIMM slot supports a minimum of 4 GB and a maximum of 8 GB.

Table 3. Video

Feature	Specification
Integrated	Intel HD Graphics 530 / 510
Discrete	PCI Express x16 graphics adapter

Table 4. Audio

Feature	Specification
Integrated	Realtek HDA Codec ALC3234

Table 5. Network

Feature	Specification
Integrated	Realtek RTL8111HSD-CG Gigabit Ethernet LAN 10/100/1000 Mb/s controller

Table 6. System information

Feature	Specification
System chipset	Intel H110
DMA channels	Two 8237 DMA controllers with seven independently programmable channels
Interrupt levels	Integrated I/O APIC capability with 24 interrupts
BIOS chip (NVRAM)	16 MB

Table 7. Expansion bus

Feature	Specification
Bus type	PCIe gen3 (x16), USB 2.0, and USB 3.0
Bus speed	PCI Express: x1 -slot each direction speed – up to 985 MB/s x16-slot each direction speed–16 GB/s
	SATA: 1.5 Gbps, 3.0 Gbps, and 6 Gbps

Table 8. Cards

Feature	Specification
PCI express x1	Half height card
PCI express x16	Half height card

Table 9. Drives

Feature	Specification
Externally accessible (5.25-inch drive bays)	Two
Optical drive	One

Table 10. External connectors

Feature	Specification
Audio
	Front panel	Universal Audio Jack
	Back panel	Line out connector
Network adapter	RJ-45 connector
Serial	9-pin connector; 16550 C compatible (optional)
Parallel	25-pin connector (optional)
USB 2.0	Front panel: two Back panel: two
USB 3.0	Front panel: two Back panel: two
Video	19-pin HDMI connector 20-pin DisplayPort connector 15-pin VGA connector (optional) NOTE: Available video connectors may vary based on the graphics card selected.
Keyboard and mouse	Back panel: PS2 Keyboard 6-pin connector (optional) PS2 Mouse 6-pin connector (optional)

Table 11. Internal connectors

Feature	Specification
PCI Express x16 data width (maximum) — 16 PCI Express lanes	164-pin connector
Serial ATA	Two 7-pin connectors
Memory	Two 240-pin connectors
Internal USB	10-pin connector
System fan	4-pin connector
Front panel control	5-pin connector
Processor	1151-pin connector
Processor fan	4-pin connector
Service mode jumper	2-pin connector
Password clear jumper	2-pin connector
RTC reset jumper	2-pin connector
Internal speaker	4-pin connector
Intruder connector	3-pin connector
Power connector	One 8-pin for PSU, one 4-pin for CPU, one 6-pin for SATA power

Table 12. Controls and
lights

Feature	Specification
Front of the computer
	Power button light	White light — Solid white light indicates power-on state; slow blinking white light indicates sleep state of the computer.
	Drive activity light	White light — Slow blinking white light indicates that the computer is reading data from or writing data to the hard drive.
Back of the computer
	Link integrity light on integrated network adapter	Green — a 10 Mbps connection exists between the network and the computer. Green — a 100 Mbps connection exists between the network and the computer. Orange — a 1000 Mbps connection exists between the network and the computer. Off (no light) — the computer is not detecting a physical connection to the network.
	Network activity light on integrated network adapter	Yellow light — A blinking yellow light indicates that network activity is present.
	Power supply diagnostic light	Green light — The power supply is turned on and is functional. The power cable must be connected to the power connector (at the back of the computer) and the electrical outlet.
